SWITCHES
Stainless Steel Low Profile Vandal Resistant - Latching
FRONT PANEL MOUNTING
Front Panel Sealed to IP66
21.5mm diameter
2A, 50Vac/dc
Single pole push to make
Latching switch
MPL031
Sealed to IP66
REAR PANEL MOUNTING
Rear Panel Mounting
Flush with Panel
19mm diameter
2A, 50Vac/dc
Single pole push to make
Latching switch
MPL034
Specification
Terminations:
Switching:
Max. Rating:
Contact Resistance:
Insulation Resistance:
Dielectric Strength:
Operating Temp. Range:
MPL031
Solder Tags
S.P.M.B. - Latching
2A, 50Vac/dc
<10m ?
>10 3 M ?
>2.0kVac
–20?C to +70?C
MPL034
Solder Tags
S.P.M.B. - Latching
2A, 50Vac/dc
<10m ?
>10 3 M ?
>2.0kVac
–20?C to +70?C
Sealing (Front of panel only) : Protection Classification: IP66 EN60529
1992 (Switch not sealed)
Operations
Mechanical:
Electrical:
Operating Pressure:
Rear Nut Fixing Torque:
Materials
Mouldings:
Tags/Terminations:
Switch Body & Button:
Contacts:
Thread size:
RoHS
www.elektron-bulgin.com
8,000 (min)
8,000 (min)
5.5N (typ)
0.57Nm
Glass Filled Nylon
Brass, Tin Plated
Stainless Steel
Fine Silver
0.747" x 26TPI
Compliant
8,000 (min)
8,000 (min)
5.5N (typ)
–
Glass Filled Nylon
Brass, Tin Plated
Stainless Steel
Fine Silver
-
Compliant
177
